Optical Len LED VMS Signs Electric Traffic Variable Information display

  • 1
  • 2

Brand Name : YAHAM

Model Number : YHT-VMS-OT20

Certification : EN12966、NTCIP

Place of Origin : Shenzhen, China

MOQ : 15 Square Meter/Square Meters

Price : $1200-2000 Square Meter/Square Meters

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 3580 Square Meter/Square Meters Per Month

Delivery Time : 22 work days

Packaging Details : WOODEN CASE

Pixels : 20mm

Display Function : Graphics, Video, Text

LED Brand : Nichia, Cree, Nationstar, Unionled

EN12966-1 standard : L3,R3,B6,C2

Protection Level : Standrad IP65

Power Supply : 110-240V AC

Contact Now

Optical Len LED VMS Signs Electric Traffic Variable Information Display

City road LED traffic information variable message sign optical len VMS products

YAHAM LED variable message signs and traffic guidanceequipment traffic information dissemination, which is based on LED lighting device shows the effect of the basic traffic information display unit of a display device with graphics and text. According to the instruction information traffic, weather and dispatching department, the operator can be released to the variable information boards of various notices and information to effectively induct traffic flow, improve transport capacity of the road network, the safety of the driver driving fast provide excellent service.

Integrate that latest manufacture technology and combining the patch manufacturing technology with the lens technology, the invention not only achieve the guarantee of the patch technology on the product stability, but also achieves the color mixing effect of the lens lamp bead.

Item YHT-VMS-OT10 YHT-VMS-OT12 YHT-VMS-OT16 YHT-VMS-OT20 YHT-VMS-OT25 YHT-VMS-OT31.25
Pixel pitch 10mm 12mm 16mm 20mm 25mm 31.25mm
LED type 3 in1 SMD+lens 3 in1 SMD+lens 3 in1 SMD+lens 3 in1 SMD+lens 3 in1 SMD+lens 3 in1 SMD+lens
Pixel density 10000 pixels/m² 6944 pixels/m² 3906 pixels/m² 2500 pixels/m² 1600 pixels/m² 1024 pixels/m²
Module dimension 320×160 mm 192×192 mm 256×128 mm 320×160 mm 200×200 mm 250×250 mm
Module resolution 32×16 16×16 16×8 16×8 8×8 8×8
Cabinet material 2mm aluminum Alloy
Screen weight 65kg/m²
Cabinet dimension 960×960 mm 960×960 mm 1024×1024 mm 960×960 mm 1000×1000 mm 1000×1000 mm
Brightness L3,L3*:EN12966 (Red: >3100nits, Green>3720nits, Blue>1240nits, Amber>7440nits, White:>12400nits)
Brightness adjustment 32/256
Color coordinates C2: EN12966 C2: EN12966 C2: EN12966 C2: EN12966 C2: EN12966 C2: EN12966
Refresh rate >90+ Hz >90+ Hz >90+ Hz >90+ Hz >90+ Hz >90+ Hz
Display control Asynchronous control system available
Display capacity Text, image, graphics animations
Lifespan >100000 hrs >100000 hrs >100000 hrs >100000 hrs >100000 hrs >100000 hrs
Power supply 12-24V DC/110-230V AC
Max. Power consumption 400W/m² 380W/m² 250W/m² 220W/m² 220W/m² 220W/m²
Avg. Power consumption 130W/m² 120W/m² 80W/m² 70W/m² 70W/m² 70W/m²
Operation temperature -25~ +60°C
Storage temperature -40~ +80°C
Store humidity 15%~ 95% 15%~ 95% 15%~ 95% 15%~ 95% 15%~ 95% 15%~ 95%
Protection level IP56(P3:12966) IP56(P3:12966) IP56(P3:12966) IP56(P3:12966) IP56(P3:12966) IP56(P3:12966)
Maintenance method Rear service Rear service Rear service Rear service Rear service Rear service
EN12966 compliance compliance compliance compliance compliance compliance

Optical Len LED VMS Signs Electric Traffic Variable Information display

Optical Len LED VMS Signs Electric Traffic Variable Information display

Optical Len LED VMS Signs Electric Traffic Variable Information display
